Fibre
Fibre Splice Tray Installation
Multi-mode fibre splice tray with LC connectors and colour-coded fibre management for easy identification and future maintenance.
Fibre
Excel Fibre Termination Box
OM4 8-fibre termination box with armoured external cable entry. Neat installation in a cupboard location for building interconnect.
Cabling
Server Rack Cable Management
Professional cable management with colour-coded Cat6 patch leads, cable trays and proper bend radius throughout.
Fit-Out
Education Sector Installation
Data and power installation along teaching bench in educational facility. Multiple data points with integrated power outlets.
Fit-Out
Classroom Trunking Installation
Surface-mounted trunking system in a school classroom providing accessible data and power points around the perimeter.
Fibre
Fibre Splice Cassette
Excel fibre splice cassette with 12 colour-coded fibres. Labelled with OLM Network Solutions for professional documentation.
Cabinet
Excel Wall Cabinet Installation
New Excel wall-mounted cabinet with fibre patch panel, 24-port copper patch panel and PDU. Clean professional installation.
Fibre
Completed Fibre Splice Cassette
Fully spliced and tested fibre cassette with LC pigtails. Labelled and documented ready for installation.
Cabinet
Network Cabinet with Cisco Switch
Complete sports hall network cabinet featuring Draka fibre, Excel patch panel, Cisco PoE switch and Excel PDU.
Wireless
Aruba Wireless Access Point
Ceiling-mounted Aruba Instant On access point. Discreet installation with proper labelling for network management.
Fibre
Fibre Breakout Enclosures
Dual fibre breakout boxes with OM3 armoured cable entry. Labelled for CAPS and Security connections.
Fibre
External Fibre Cabinet
Outdoor-rated fibre enclosure for security hut connection. OM3 8-fibre armoured cable with proper gland entry.
Fit-Out
College Fit-Out In Progress
First fix Cat6 cabling installation with dado trunking. Multiple data drops being pulled ready for termination.
Testing
Cabinet Ready for Testing
Draka Cat6 patch panels with 96 ports terminated and labelled, ready for Fluke DSX certification testing.
Cabinet
Full Height Server Cabinet
Academy school main distribution frame. Full 42U cabinet with multiple Excel patch panels and cable management.
Cabling
Excel Patch Panel Installation
Multiple Excel 24-port Cat6 patch panels with proper cable management bars and labelling throughout.
Fit-Out
Time & Attendance Terminal
UKG time and attendance terminal with network data point. Surface-mounted mini trunking for cable containment.
Fit-Out
Floor Box Installation
Raised floor box with quad power sockets and dual data outlets. Ideal for open-plan offices and hot-desking areas.
Testing
OTDR Fibre Testing
Professional OTDR testing of fibre installation to verify splice quality, measure loss, and document the complete link.
